CASE STUDY OVERVIEW
High-Voltage 33kV Substation
Electrical Munich, Germany 2025 Bavarian Grid Authority
Development of an eco-friendly vacuum-interrupted switchgear line with integrated gas leakage sensors and high-speed busbar switches.
The Engineering Challenge
The legacy oil-insulated breakers posed a significant environmental risk and struggled to handle sudden load surges from a nearby foundry, causing frequent arc-flash events.
The Custom Solution
Installed vacuum-break medium-voltage switchgear with our Titan Grid-Switch system. Configured smart protective relays linked back to the SCADA control room with real-time partial discharge monitoring.
Performance Outcome Metrics (KPIs)
Uptime99.97%
Oil Hazard100% eliminated
Load Capacity+50% peak handling
Arc Extinction< 10ms response
